Large House AutoCAD DWG Plan with Bedrooms Lounge Kitchen Lawn

This AutoCAD DWG house layout features an expansive residential design with a 103 ft 6 in length and multiple rooms arranged around open lanes and wide verandahs. The plan includes three bedrooms sized 17 ft x 16 ft, each paired with bathrooms measuring 10 ft x 5 ft and open spaces of 24 ft 6 in x 5 ft 6 in. The ground floor highlights a spacious 28 ft 6 in x 18 ft TV lounge, a 17 ft 6 in x 18 ft entrance lobby, a 9 ft x 12 ft kitchen, and a 17 ft 6 in x 24 ft car porch for convenient parking. A central landscaped lawn of 26 ft x 24 ft is surrounded by 4 ft and 6 ft wide passages, creating a well-ventilated and interconnected layout ideal for large families.

The first floor includes bedrooms sized 17 ft x 16 ft, a 13 ft 6 in x 14 ft 6 in lavatory, a 7 ft x 7 ft bath, a 7 ft x 7 ft wash area, and a 28 ft 6 in x 23 ft 9 in roof terrace that opens to the sky. Additional facilities such as a 17 ft x 16 ft store, open terraces, and an overhead water tank area provide complete functional detailing for the residence. Projection lines, circulation routes, and wide verandahs measuring 12 ft enhance comfort and openness across the layout. This DWG file is valuable for architects, civil engineers, interior designers, builders, and CAD professionals seeking a fully dimensioned residential plan.
