Autocad Roof Water Tank Plan with Pump Room and Level Details

This roof-level cad drawing shows two large reinforced concrete water tanks designed for domestic, fire reserve, and irrigation use. Both tanks are dimensioned 27 m x 6.6 m x 5.85 m (high), each holding 975.5 m³ or 257,532 US gallons. The layout displays LEVEL 1, LEVEL 2A, LEVEL 2B, LEVEL 3A, LEVEL 3B, and LEVEL 4A (roof) markers across the structure, helping engineers understand elevation references.

The pump room is placed adjacent to the tanks, supporting the complete water distribution system. Structural annotations indicate match lines between sections and roof slab alignment. All tank compartments, height markers, and service zones are clearly drafted for accurate construction coordination. This AutoCAD DWG provides essential information for architects, civil engineers, and MEP professionals working on large-scale water storage and building service planning.
