Residential DWG Plan with Multi Proposal Layouts and Floor Details

This detailed multi-floor house AutoCAD DWG file presents complete architectural plans for a 21 ft x 50 ft residential layout, featuring ground, first, and mezzanine floor drawings. The ground floor includes a kitchen 7 ft 6 in x 10 ft, lounge 13 ft x 14 ft, drawing room 9 ft x 17 ft 6 in, bedroom 12 ft x 14 ft, car porch 10 ft 6 in x 17 ft, and multiple bath spaces ranging from 4 ft x 8 ft to 7 ft 6 in x 6 ft, along with open areas and washing zones as shown in the PDF

The first floor expands the plan with bedrooms sized 12 ft 6 in x 17 ft 6 in, 12 ft x 14 ft, a balcony 3 ft 6 in wide, staircases between 7 ft x 17 ft and 7 ft 6 in x 15 ft, lounges, open-to-sky spaces, multiple baths measuring 6 ft 6 in x 4 ft 6 in, 7 ft x 3 ft 6 in, and kitchen areas from 5 ft 6 in x 8 ft to 6 ft 6 in x 7 ft 6 in. Also included are alternative proposals with rooms up to 16 ft 3 in x 12 ft, hall 22 ft x 26 ft 6 in, porch 13 ft x 17 ft, well duct 7 ft x 4 ft, and lounge & kitchen 19 ft 6 in x 12 ft, providing architects and designers with multiple design options for residential planning
