Three Storey Residential Block DWG with Full Structural Details

The uploaded AutoCAD DWG file provides a complete architectural and structural set for a three-storey residential block, including floor plans, roof layout, roof framing plan, foundation layout, site development plan, elevations, sections, and construction notes. The drawings display accurate grid lines, column locations, beam sizes, footing dimensions, slab reinforcement layouts, and sectional roof slopes. The foundation plan includes isolated footing measurements and reinforcement detailing following standard residential building requirements. The roof plan and roof framing plan illustrate rafter spacing, purlin positions, gutter lines, and ridge levels, delivering full clarity for site execution.n This DWG also includes general notes, specifications, structural schedules, framing details, column schedules, and a complete site layout with property boundaries and setback dimensions. Elevations show front, rear, and side views with height levels, window sizes, and façade detailing. Sectional drawings clearly indicate slab thickness, footing depths, stair dimensions, wall construction, and reinforcement sections essential for architects, civil engineers, interior designers, and builders working on residential block projects. Downloading this file gives professionals a comprehensive reference to speed up their drafting workflow and ensure compliance with residential construction standards
