Basement Medical Facility AutoCAD Plan with Full Room Measurements

This Basement Medical Facility AutoCAD plan provides a complete layout of the proposed basement level for the residence project at Rewari. The drawing includes full room measurements such as a general ward of 14 ft 6 in x 30 ft 3 in, multiple chambers of 11 ft 3 in x 8 ft 0 in, private ward spaces of 11 ft 3 in x 8 ft 0 in, and an operation theatre measuring 11 ft 3 in x 12 ft 6 in. The design also features a stretcher lift of 6 ft 0 in x 8 ft 6 in, a staircase of 11 ft 0 in x 16 ft 6 in, toilet units with accurate dimensions, a multipurpose room sized 10 ft 7 in x 17 ft 6 in, and a lab area of 11 ft 3 in x 7 ft 6 in. A wide corridor layout of 7 ft 6 in ensures smooth internal circulation, along with an optical shop area measured at 11 ft 3 in x 19 ft 2 in. All measurements are clearly displayed and organized to support medical functionality and basement-level planning.

This AutoCAD DWG drawing is ideal for architects, civil engineers, interior designers, builders, and design professionals working with AutoCAD, Revit, SketchUp, and 3d Max who require a technically complete basement medical layout. The detailed room sizing, corridor widths, lift placements, and service room distribution make this file suitable for planning, design development, and construction coordination. Access to this drawing through a Cadbull subscription helps users obtain high-quality and fully measured basement plan resources for professional design projects.
