Two Storey Residential House Drawing Set With Plans, Elevation details

This AutoCAD drawing set presents a complete two-storey residential house design with coordinated architectural, structural, and services drawings. The file includes proposed ground floor and second floor plans prepared at a 1:100 scale, clearly showing room layouts such as living area, dining, kitchen, bedrooms, toilets, balcony, staircase, and circulation spaces with detailed dimensions in meters. Elevation drawings illustrate front, rear, and side views with finish annotations including plastered walls, textured paint, fixed glass panels, canopy details, and finished floor levels marked from natural ground level to roof height. A proposed perspective view is also included to visually represent the building massing and façade treatment.

In addition, the drawing set covers foundation plans, column layouts, beam plans, and roof framing details with rafter and purlin spacing clearly indicated. Structural notes, column schedules, and beam schedules provide reinforcement sizes and layout references. Electrical lighting and power layouts, plumbing, water supply, and sewer line layouts, septic tank and catch basin details are included for full service coordination. Site-related drawings, such as a vicinity map, a location map, and a site development plan, help define plot orientation and access. This residential AutoCAD drawing set is suitable for architects, engineers, and builders requiring a well-coordinated two-storey house plan with elevations, sections, and service drawings for construction documentation.
