Central Station Window Schedule DWG with 300 to 1700 mm Sizes

This AutoCAD DWG file presents a complete window schedule for a central station building, detailing aluminium framed windows with structural opening sizes ranging from 931×300 mm to 1300×1700 mm. The drawing includes window types W01 to W17, room-wise allocation for WC, cleaner rooms, kiosks, cantina, manager's office, and ticket areas, along with elevation references, FFL levels, RC beam and lintel heights, and wall thickness of 110 mm and 280 mm masonry. Each window specification defines powder-coated aluminium frames, intruderproof 6.38 mm laminated safety glass, outward-opening sections, louvre panels, and shopfront-style assemblies. This professional working drawing follows construction standards, millimetre-based dimensions, and site-ready fabrication notes, making it ideal for architects, civil engineers, and interior designers working on transport hubs, commercial buildings, and public infrastructure projects, supplemented by interior reference resources such as 2D CAD blocks of wardrobe sections with clothing details and table–chair set blocks prepared in AutoCAD DWG format for space planning support.
