Steel Door Detail CAD Drawing with 1000x2100mm Frame Designs

This professional CAD DWG file presents a complete steel door detail drawing with precise dimensions and construction references, ideal for architects, civil engineers, and interior designers. The drawing includes door elevation, section details, welded frame construction, interlocking door leaf profile, anchor bolt fixing, perimeter seal, rubber plug, and frame jamb details. The door opening is designed with a 1000mm width and 2100mm height, featuring a 1.5mm thick GI steel frame and 1.2mm thick GI shutter with polyester powder coating. Clear annotations show the handle center at 1025mm, hinge positioning, threshold requirements, and wall interface sections with mortar infill. This DWG file also includes material schedules, hardware specifications, fire rating notes, and electronic access coordination references, making it suitable for commercial buildings, corridors, and safety zones. The file is fully editable and compatible with AutoCAD, Revit, 3ds Max, and SketchUp workflows, helping professionals save design time while maintaining construction accuracy and industry standards. The DWG package also contains a detailed sofa plan with attached side table for interior layout reference and furniture coordination.
