Door Windows Schedule And Frame Section Detail Drawing files

Door window schedule and frame section detail drawing showing complete architectural documentation of door and window types with dimension references and installation details. The sheet includes a detailed door schedule listing various door sizes such as 2 ft 6 in by 7 ft 0 in and 3 ft 0 in by 7 ft 0 in, along with door types, swing door, sliding door, and screen door with aluminum frame specifications. Window elevation drawings illustrate frame width, height, glass panel configuration, and opening direction with dimension annotations. Additional construction details include an aluminum sill section, hollow metal frame wall connection, floor base detail, wood frame partition section, and hollow metal frame installation within concrete unit wall assemblies. These door window schedule and frame section detail drawings provide accurate measurements, frame profiles, material specifications, and architectural references used for door and window installation planning and building construction documentation.
