Perimeter Fence Elevation 3500 3250 2800 Height Gate DWG Plan

This AutoCAD DWG drawing showcases a complete Perimeter Fence Elevation with detailed front, left, right, and rear views designed at a scale of 1:20. The front fence elevation includes a gate width of 3500 with adjoining panels of 3250 and 3250, and height variations up to 2900 and 2050. The structure uses GI rectangular tube framing with dimensions 1.5 x 2.5 x 3 mm and 1 x 1 x 3 mm for gate and panel support. The left elevation highlights the CHB wall construction with 16 mm plaster thickness on both sides and dimensions 1400 and 2000 width with a height of 2800. Rear and right fence elevations maintain a uniform height of 2800 with solid wall detailing and sloped coping design. The drawing clearly defines spacing, structural members, material specifications, and elevation proportions for accurate construction and fabrication. This Perimeter Fence Elevation DWG is ideal for architects and engineers requiring precise gate and boundary wall detailing for residential projects.
