Defence Aviation Gallery Ahmedabad Sections CC DD DWG Levels

This detailed Defence Aviation Gallery Ahmedabad Section CC DD DWG Levels drawing presents sectional architectural information of a complex gallery structure with precise vertical level references and spatial organization. The plan includes Section CC and Section DD views at scale 1 to 250, clearly illustrating multiple floor levels, such as the ground floor at 600 mm, first floor at 6600 mm, second floor at 12600 mm, terrace roof level at 18600 mm, and gallery roof level reaching up to 24600 mm. Mezzanine levels, including ground floor mezzanine at 3600 mm, first floor mezzanine at 9600 mm, and second floor mezzanine at 15600 mm, are also defined. The drawing highlights radial planning geometry, central circular core circulation, staircases marked UP and DN, and symmetrical spatial distribution across the gallery wings. Structural grids V1 to V7, sectional cut lines CC and DD, and architectural massing provide a complete understanding of the building form.
