495x600 Duct Assembly with Support and Fabrication CAD Details
Frequently Asked Questions
The drawing includes a 495x600 duct assembly, 200x800 aluminum cover, 800mm and 200mm supports, face channels, sections, bends, dimensions, and fabrication details.
E-E-A-T & Quality Verification
📝 AI Overview (TL;DR)
Complete AutoCAD drawing set featuring a 495x600 duct assembly, 200x800 aluminum duct cover, 800mm and 200mm duct supports, 800mm and 200mm face channels, with fabrication dimensions, bends, sections, material specifications, and sheet metal details for HVAC fabrication.
💡 First-hand Experience
This CAD drawing helps streamline HVAC duct fabrication by providing production ready layouts, accurate dimensions, detailed sheet metal profiles, and assembly references that reduce drafting time and improve installation accuracy.
Ratings & Reviews
Be the first to share your experience with this product. Your review helps others make better decisions!
Description
This AutoCAD drawing includes a complete 495x600 duct assembly with detailed fabrication layouts for a 200x800 aluminum duct cover, 800mm and 200mm duct supports, 800mm and 200mm face channels, and assembly components. The drawing contains plan views, elevations, sectional views, profile bends, isometric details, sheet thickness, weld references, and manufacturing dimensions for accurate fabrication and installation. Designed for HVAC projects, this file helps architects, mechanical engineers, builders, fabricators, and CAD professionals prepare precise construction documentation. The detailed dimensions, fabrication notes, material specifications, and assembly references ensure compatibility with AutoCAD, Revit, 3D Max, and Google SketchUp workflows for professional sheet metal and duct fabrication projects.
File Type:
DWG
File Size:
355 KB
Category::
Mechanical and Machinery
Sub Category::
Mechanical Engineering
type:
Gold
Tags
Uploaded by:
Vaas
