This AutoCAD DWG drawing provides a complete and highly detailed P51 Mustang aircraft model plan, showcasing the full fuselage structure, wing design, stabilizers, and internal framing components required for accurate model construction. The drawing includes a full set of formers labeled F1, F1A, F2, F2A, F3, F3A, F4, F4A, F5, F5A, F7, F7A, F8, F8A, F9, F9A, along with clearly shaped wing ribs arranged in order. Materials and dimensions such as balsa 3, balsa 5, balsa 8, balsa 12, and pioppo 3 are marked throughout the plan, allowing builders to select the correct thicknesses for each structural part. The fuselage layout displays detailed reinforcements, battery support base, longheroni, air intakes, wing saddles, and vertical stabilizer structure with accurate alignment lines.

The wing section of the drawing presents rib spacing, dihedral angle, aileron sections, wing tips, and detailed reinforcement instructions, including glass-fiber layers of 100 g/m² and 40 g/m² applied to critical zones. Additional technical information, such as motor power 600–700 watts and KV 1000–1100, helps users determine propulsion compatibility for RC model building. Catapult hook placement, servo housing areas, and shaping guidelines for the rudder and elevator are also clearly indicated. This DWG layout is ideal for RC aircraft modelers, hobby engineers, and aviation designers seeking an accurate, editable, and construction-ready P51 Mustang plan

Airport plan detail view dwg file
