Ornamental hoop pool construction details dwg file


Description

Ornamental hoop pool construction details dwg file Ornamental hoop pool construction details that includes a detailed view of Ornamental hoop pool internal 48 nozzles 1/2 " 1/4", flange supply with inox bolts, aro ornamental transversal cut, connection details, reflecting plate and much more of hoop pool details.



Vaishali
India
File Type: DWG ID: 33744
