Cut floor ceiling raster metal construction details dwg file


Description

Cut floor ceiling raster metal construction details dwg file. Cut floor ceiling raster metal construction details that includes a detailed view of supportive concrete base construction, supportive column and beam construction, pillar construction, slab construction, measures, cuts, joints and much more of cut floor ceiling details.




File Type: DWG File ID: 34404

Uploaded by:


Vaishali
India
