Modern Senior Living Hall AutoCAD Design with Floor Plan and Elevation

This modern senior living hall AutoCAD design provides a clear, well-structured layout suitable for retirement homes, assisted living facilities, and community-focused senior spaces. The plan features a total built-up area of 300 sq meters, divided into a 173 sq meter ground floor and an 87 sq meter upper floor. The octagonal floor plan displays organized seating arrangements, circulation paths, and surrounding structural bays labeled from A to G. Detailed elevation views, including front, rear, left, and right sides, highlight key architectural elements such as steel railings, wooden shutters, tiled roofing, and extended verandah shading. Each elevation is dimensioned precisely to support accurate execution and presentation.

The sectional drawing (Section Thru A) provides a complete understanding of the internal height, column positions, roof layering, and spatial functionality tailored for senior-friendly movement. This AutoCAD model serves architects, interior designers, civil engineers, and builders looking for accessible and safe senior living concepts. The hall design is adaptable for multipurpose use yoga sessions, dining areas, recreational meetings, or community activities while maintaining a calm and secure environment for elderly users. This file supports efficient planning, project detailing, and professional-grade senior living design documentation.
