Health Centre Building Plan with Treatment Rooms and Waiting Area

This Health Centre Building Plan DWG showcases a compact and efficient medical facility layout designed to support essential healthcare services within a small-scale structure. The floor plan includes consultation rooms, treatment areas, a waiting zone, restrooms, medicine storage, and administrative spaces arranged for smooth circulation and ease of access. The layout features clear zoning that separates public, semi-private, and staff-only areas, ensuring both patient privacy and operational efficiency. Wide entrances, functional furniture arrangements, and simple corridor connections contribute to a user-friendly environment suitable for community health centers and rural clinics.

The project also includes front, side, and sectional elevations that highlight the building’s architectural simplicity and practical construction style. The use of a pitched roof, natural ventilation openings, and balanced window placement supports a comfortable indoor atmosphere. The sectional drawings reveal structural elements, foundation detailing, and internal height distribution, helping architects and builders understand the technical aspects of the design. With its straightforward layout and thoughtful spatial planning, this design serves as an excellent reference for professionals developing small medical facilities. It is ideal for healthcare planners, architects, engineers, and students seeking guidance on creating accessible, efficient, and cost-effective health centre buildings
