Hospital electrical and hydraulic symbol legend AutoCAD DWG guide

This AutoCAD DWG file provides a detailed and complete legend of hospital electrical and hydraulic symbols, supporting accurate planning, installation, and documentation for healthcare projects. The drawing includes a wide range of electrical components such as ceiling incandescent lamps, sodium lamps, mercury lamps, halogen lamps, and reflectors, along with multiple fluorescent fixtures in 2 x 48", 1 x 48", 2 x 24", 1 x 24", 4 x 96", and 2 x 96" configurations. It also shows various power outlets and switches, including single and double-phase outlets, grounded outlets, three-phase outlets, TV antenna points, nurse call buttons, safety switches, single, double, and triple switches, as well as breakers, fuses, grounding connections, and UPS symbols. Each symbol is clearly represented to ensure precise interpretation during electrical layout development.

The file further includes communication system symbols, such as telephone points, direct line connections, extension points, fax outlets, public phone connections, and intercom points. Hydraulic symbols are also listed in detail, including cold water outlets, hot water outlets, gate valves, globe valves, floor drains, sump drains, water meters, inspection boxes, inspection pits, and fire cabinet indicators. Every symbol in the legend is illustrated with its corresponding icon, making this DWG support highly useful for designing hospital electrical networks, communication systems, and plumbing layouts with technical accuracy.
