Children Playground Layout with Pavilion Pathways and Seating Areas

This drawing presents a complete children playground layout, featuring a symmetrical site design with structured pathways, landscaped segments, and central activity zones. The plan includes a clearly defined central pavilion with an octagonal shape surrounded by patterned walkways. Two large curved play areas appear on both ends of the site, each designed with dedicated seating arrangements, planted borders, and ample open space for child-friendly recreation. The middle section connects these areas through four intersecting pathways, highlighted by different pavement textures such as stone patterns, tile grids, and landscaped inserts. The surrounding zones include benches, small trees, shrubs, lamp posts, and pergola-style elements that frame the circulation routes and resting points.

The elevation sheets show the façade principale, including pergolas, lamp posts, trees, and the detailed pavilion structure with columns, railings, and roof profiles. Additional sections illustrate side views of the pergolas, benches, playground boundaries, and decorative garden elements, helping visualize the height relationships and architectural characteristics on the site. Smaller drawings depict the pavilion from multiple angles, demonstrating its geometric arrangement and material indication lines. This layout offers a complete representation of a well-organized outdoor children’s play environment, integrating recreational zones, landscaped paths, architectural components, and clear visual orientation.
