Kitchen Detail AutoCAD DWG with Cabinet Layout and Working Dimensions

This Kitchen Detail AutoCAD DWG file provides a professionally drafted drawing with complete cabinet layout, sectional views, and working dimension details for residential and commercial kitchens. The plan includes base cabinets with standard heights of approximately 850 mm, wall units with a depth of approximately 600 mm, countertop widths of approximately 600 mm, and overhead storage placement. It also shows sink location, hob and chimney positioning, refrigerator space, microwave shelf, and preparation counters. Clearances between working zones are maintained at nearly 1200 mm for comfortable movement. Accurate measurements, material thickness, fixing methods, and alignment markings are clearly indicated for precise fabrication and installation. This kitchen layout drawing is suitable for apartments, villas, hotels, staff housing, and commercial pantry projects.
