Clinic Centre Design AutoCAD DWG With Floor Plan And Elevation

This Clinic Centre Design AutoCAD DWG file presents a complete architectural and functional layout for modern healthcare facilities. The drawing set includes a detailed site layout, ground floor plan, upper floor plan, OPD consultation rooms, treatment cabins, waiting lounge, reception counter, pharmacy unit, diagnostic area, laboratory space, staff rooms, storage areas, and sanitary facilities. It also illustrates staircase and lift core placement, emergency exit routes, corridor widths, service circulation, and ventilation shafts. All plans are prepared with proper scale, grid lines, wall thickness, column alignment, and setback details. Accurate room measurements, bed spacing, passage clearances, and level annotations ensure smooth coordination for construction and interior execution.
