Club House Detail Plan With Site Layout And Landscape 80x60m

This clubhouse detail plan presents a complete 80x60m site layout integrating building footprint, landscape design, and circulation planning. The clubhouse detail plan includes the main hall, multipurpose activity rooms, meeting spaces, reception area, service rooms, and internal corridors with accurate dimensioning. The drawing clearly defines structural grid alignment, wall thickness, door and window openings, and spatial zoning. External areas show landscaped gardens, a central open plaza, a pathway network, a parking layout, and boundary limits within the 80x60m site. Each space is proportioned with precise measurements to support architectural planning and coordinated execution. The drawing set also illustrates elevation references and sectional indications showing floor height, roof profile, and facade detailing of the clubhouse building. Entry access points, driveway alignment, pedestrian movement paths, and green buffers are clearly marked. The clubhouse detail plan highlights furniture arrangement, activity zones, and service utilities positioned for functional efficiency.
