Single family house framing and layout plan details dwg file

Description:

Single family house framing and layout plan details that includes a detailed view of wood posts, joints, decking, grider pre-engineering, steel pipe column, play joints, existing floor joints, knee wall, steel pipe column, beam schedule details, dimensions details, measures with main entry house door, drawing room, living room, family hall, kitchen, dining area, indoor staircases, laundry area, balcony, bedroom, master bedroom, toilets and bathroom, indoor doors and much more of house project.

Category : Cad Architecture
Sub category : Architecture House Plan CAD Drawings
File Type : Autocad
File ID : 61554
Type : Gold
Size : 1640.59 KB
