Constructive section and sanitary installation details of university canteen dwg file

Description:

Constructive section and sanitary installation details of university canteen that includes a detailed view of flooring view, wall construction, memory of materials, footings details, column view, beam construction, covers closure type, soil burried wall closure , exterior solera, holes, interior partition, granite veneer of the country with steel supports, halfeneisen type, Brick partition, plaster plastering, Concrete wall and much more of canteen details.



Category : Detail
Sub category : Construction detail
File Type : Autocad
File ID : 61564
Type : Gold
Size : 2537.79 KB
Publisher
Vaishali
