Multiple wall construction details of building dwg file

Description:

Multiple wall construction details of building that includes a detailed view of layer- wall core polystyrene base material thickness of, layer-3 of wall of "to the base of concrete of thickness, concrete chain, rebar steel rod ", stirrup for chain frame ", Hollow for fastening and assembly. pvc base material, round "so" for post-tensioning, steel plate, see detail pl, reinforcement rod square cms and much more of wall details.



Category : Detail
Sub category : Construction detail
File Type : Autocad
File ID : 61880
Type : Gold
Size : 212.19 KB
