Ground and first floor framing plan details of office building dwg file

Description:

Ground and first floor framing plan details of office building that includes a detailed view of wood posts, joints, decking, grider pre-engineering, steel pipe column, play joints, existing floor joints, knee wall, steel pipe column, beam schedule details, dimensions details, measures and much more of framing plan details.

Category : Detail
Sub category : Structure detail
File Type : Autocad
File ID : 62400
Type : Gold
Size : 116.77 KB
