Hygiene services section, plan and installation details dwg file

Total Downloads

0

Reviews

  • (35)

Favorities

0

Hygiene services section, plan and installation details dwg file Details

Hygiene services section, plan and installation details that includes a detailed view of toilet plan, floaded elevation of toilet, toilet sections and elevations, doors and ventilations, plumbing details, evc with flush tank, ewc with flush tank, urinals with sensor, wash basin, fd- floor drain, bib cock, health faucet, angle stop cock, piller cock, paper holder, soap dispenser toshi, granite counter, mirror frame, towel rail/ring and much more of sanitary installation details.
