Roof construction details with water sewer system dwg file


Roof construction details with water sewer system that includes a detailed view of Smooth embossed and riveted zinc-alum roof, vapor barrier. dynafoil asphalt felt, structural osb board, expanded polystyrene, Extruded plywood, Piece pine wood, brushed dry, Vapor, concrete base, placement of luminaire in the f.c.r. of fiber plates, mineral types zumtobel staff panos-hf-200, detail "a" detail of change of level of acoustic tiles, isometry of baldosa acustica, general plant, detail "c" false sky skull of flying and closing, main tee profile of suspension system 3.66 15/16 white color galvanized wire number 12 minimum 6 turns of tilting, cielo raso of acoustic tiles of mineral fiber and much more of roof details.

Category : Detail
Sub category : Construction detail
File Type : Autocad
File ID : 62756
Type : Gold
Size : 6202.38 KB
