Roof and wall construction details of industrial plant dwg file


Description

Roof and wall construction details of industrial plant that includes a detailed view of previously linked support, multilayer insulation panel, rubber shock absorber element, galvanized profile for anchorage, acoustic sandwich. (see detail), dimensions details, memory of materials, concrete details, cuts and joints details, reinforcement details, water proofing details and much more of roof structure details.



Vaishali
India
File Type: DWG ID: 63847
