Residential Two Floor Home Layout Design with Room Dimensions

This AutoCAD DWG file shows a complete residential double-storey house floor plan drawing based on the uploaded images. The drawing includes ground floor and first floor layouts with clearly arranged living room, dining area, kitchen, staircase, bedrooms, and bathrooms. All spaces are properly organised with visible wall thickness, door swings, window placement, and furniture symbols. The plans also display accurate room proportions, internal circulation, and structural alignment according to standard residential design practices.

The first floor plan presents multiple bedrooms, attached and common bathrooms, a lobby space, and a staircase connection as shown in the images. Each floor layout is drafted with precise dimensions, centerline markings, and boundary measurements for construction reference. The drawing reflects proper ventilation planning, entry access, and functional zoning. This CAD file represents a professional house layout suitable for architectural planning, residential drafting, and construction documentation, exactly matching the visual details provided in the uploaded floor plan images.
