Column sections and structure details for staircases dwg file


Description

Column sections and structure details for staircases that includes a detailed view of typical transverse reinforcement details with typical splice location for column, details of beam reinforcement passing through column with column junction details with dimensions details and much more of column details.




File Type: DWG File ID: 74839

Uploaded by:


Eiz Luna
New-Zealand
