Hospital structure detail cad file

2d hospital construction cad file includes foundation detail, outdoor slab detail, column detail, sanitaryware, and furniture detail, staircase detail includes The vertical distance between two successive steps is termed as riser (Fig.9.20.2b). The dimension of the riser ranges from 150 mm for public buildings to 190 mm for hospital drawing.
