window detail with sectional view cad file

Followinmg the detail are mension about window detail with sectional plan

1. LEH ALUMINUM PROFILE 24-81
2. LEH ALUMINUM PROFILE 18-82
3. PLATINUM VENTILATION GRID 1 "x3 / 16" FORMULATING 60 cm MODULES. REMOVABLE
4. GLASS e = 6mm.
5. IRON 2 "x2" x3 / 16 "TO FIX DRESS
6. VERTICAL PROFILE TYPE U-18-030
7. TWO COUPLED PROFILES TYPE "L-47"
8. WOOD TACO 5x5x8 c / 40cm.
9. PROFILE "L-47"
10.ACTUATOR ACCORDING TO NOTE
11. FINISHED IRON BALAUSTRADA: MATTE ANTI-CORROSIVE PAINT
12. 1Ø ¼ "C / 75cm. (EACH BOARD)
13. YUTE AND NYLON FOLDER PLACED ACCORDING TO MANUFACTURER'S SPESIFICATIONS
