2d CAD drawings details of RCC structural blocks dwg AutoCAD file


Description

2d CAD drawings details of RCC structural blocks dwg AutoCAD file that shows foundation structure details with concrete pad foundation details. Reinforcement details in tension and compression zone along with main and distribution hook up and bent up bars details. The stricture is a reinforced concrete cement (RCC) structure.




File Type: DWG File ID: 82912
