Gutter connection structure and construction details dwg file


Description

Gutter connection structure and construction details that includes that includes a detailed view of Reinforced concrete parapet with Stuffed with tezontle with average thickness, Stuck with cement-sand mortar prop with Waterproofing based on prefabricated membrane, Wall concrete hollow block smooth finish with based on granitic acrylic resins provide.




File Type: DWG File ID: 85675

Uploaded by:


Eiz Luna
New-Zealand
