Baden Plan 12.00m Stone Masonry Section Layout Drawing Dimensions

The Baden plan 12.00m stone masonry section layout presents a detailed structural drawing with clear dimensional references and construction levels. This section layout includes a total length of 12.00m, defined curvature geometry, and accurately marked sectional views A A and B B. The drawing highlights stone masonry construction with 40cm wall thickness, base concrete support, and clearly defined structural layers. Slope gradients of 5 percent and 4 percent are indicated for proper surface drainage and stability within the masonry section drawing.
