Horizontal Anchor System Section Detail 1 4 1 2 5 Scale Layout

This horizontal anchor system section detail drawing presents complete seccion vertical and seccion horizontal section views with precise fixing components and dimensional references. The drawing includes Detail 1 and Detail 2 at 1 4 scale and Detail 3 at 1 2 5 scale, clearly illustrating anchor brackets, stainless steel screws M8, nylon taco anchors, and adjustable support profiles. The wall assembly shows exterior ceramic cladding panels, air cavity space, thermal insulation layer, and structural backing wall alignment. Each anchor system detail defines bolt positioning, bracket offset distance, panel joint spacing, and fixing depth to ensure accurate installation.
