Gas installation system details for hot water for house dwg file


Description

Gas installation system details for hot water for house that includes a detailed view of inst. tap, nickel-plated bronze swan neck wrench and gas socket with bronze piton with Contrazocalo tile, stainless steel laundry, white mayolica, mayolica cut, porcelain filling, rubber protector, stainless steel laundry, for hose connection, simple union and much more of installation details.




File Type: DWG File ID: 90848

Uploaded by:


Eiz Luna
New-Zealand
