Water tank drawings details plan and section autocad file
Ratings & Reviews
⭐
No Reviews Yet
Be the first to share your experience with this product. Your review helps others make better decisions!
★★★★★
Description
Water tank drawings details plan and section autocad file that shows a work plan of plumbing tank blocks with section line detail and different plumbing blocks details of pipe system and valve details. Tank capacity and height width details with tank section details are also shown in the drawing.
Tags
#water tank#pipe units#RCC structure#valve#dimension#dimension#capacity#electrical motor#section line#autocad#drawings#autodesk#cad block#design.
