High Rise Tower Sky Apartment Building Floor Plan DWG Drawing File

A high-rise tower sky apartment building floor plan DWG CAD drawing file is provided here, featuring the detailed fire alarm system layout of the iconic Palais Royale located in Mumbai. This CAD drawing showcases the complete architectural planning and safety layout of a modern multi-storey residential structure. The drawing highlights the apartment’s spatial organization, service areas, and critical safety installations, making it a valuable reference for architects, civil engineers, and design professionals. The layout offers a clear understanding of the building’s vertical circulation, room divisions, and fire safety mechanisms, ensuring both efficiency and structural safety in design execution.

This DWG CAD file is an essential tool for professionals involved in high-rise building design and safety planning. It helps engineers and designers save time by providing a ready-to-use reference that complies with modern construction and safety standards. The inclusion of fire alarm system details adds a layer of technical accuracy that supports real-world implementation and compliance with safety codes. Ideal for use in architectural documentation, planning, and client presentations, this file helps visualize complex structural layouts effectively.
