Housing Area Multi Axis Elevation With Terrace Tank Drawings

This housing area multi axis elevation AutoCAD drawing presents a complete residential building elevation with clear architectural detailing. The drawing includes front and side elevations along different axes, showing floor to floor levels, ground level treatment, wall thickness details, door and window positions, stair layout, and slab alignment. The residential structure is illustrated with accurate level markings, floor heights, parapet height, and wall support details, making it useful for architectural planning and construction reference. The terrace level clearly indicates the overhead water tank position with base support and slab detailing, ensuring functional clarity for water storage planning in housing projects.The housing elevation AutoCAD drawing also covers sectional elevation details such as staircase riser and tread proportions, lintel and sill levels, and structural wall alignment from ground floor to terrace. The tank placement on the terrace is shown with proper clearance, floor level reference, and structural support detail.
