This Door and Windows <a href="https://cadbull.com/Detail" rel="noopener noreferrer" target="_blank">Detail </a>drawing presents a complete set of <a href="https://cadbull.com/Cad-Architecture" rel="noopener noreferrer" target="_blank">architectural </a>joinery specifications prepared in AutoCAD format with 2.10m standard door height and sectional frame details. The file includes front elevations of single and double-leaf doors, sliding window units, and wardrobe shutter layouts with accurate dimension markings. Each unit is supported by sectional views showing frame thickness, wall junction, lintel level, sill height, and fixing methods. Material specifications such as wood, aluminum, glass panels, and hardware fittings are clearly defined to ensure precise fabrication and installation.

Door and Windows Detail 2.10m Height Section Frame Layout Plan
