Scrolling Door Detail Drawing Showing Shutter Frame Motor Section

This Scrolling Door Details DWG file presents a complete construction drawing of a motorized rolling shutter door with precise dimensional information. The elevation view shows a double shutter opening with an overall width of 140.0 cm, individual panel widths of 61.8 cm and 75.2 cm, and a clear door height of 215.0 cm. Floor level, finished floor marking, and slab references are clearly indicated for accurate installation. The drawing also includes side clearance dimensions, handle positioning, and frame thickness, helping users understand shutter alignment within the wall opening. The Scrolling Door Detail Design DWG also includes sectional views of the shutter box, motor unit, guide rails, and base fixing.
