Column construction detail 2d view CAD structural block layout file in autocad format


Description

Column construction detail 2d view CAD structural block layout file in autocad format, reinforcement detail in tension and compression zone, column foundation detail, cut out detail, stirrups detail, main and distribution bars detail, hook up and bent up bars detail, top elevation detail, overlapping detail, bar dimension detail, specification detail, scale detail, reinforced concrete cement (RCC) structure, etc.



Presenting the broken author avatar :D Eiz Luna
New-Zealand
File Type: DWG ID: 118051
