Mosque Drawing 3D AutoCAD DWG Isometric Plan with 45x30m Layout

This mosque drawing 3D AutoCAD DWG file presents a detailed isometric layout prepared for a site area of approximately 45x30 meters with a well-organized prayer hall and sitting zone arrangement. The drawing shows the main prayer space measuring nearly 28x18 meters, surrounded by circulation corridors of about 2.5 meters in width for smooth movement. The layout includes clearly defined entrance zones, ablution area placement, mihrab alignment, minbar location, and internal partition walls with an average thickness of 200 mm. Structural columns of around 400x400 mm are arranged in a balanced grid to support roof loads and maintain open prayer space. Hatching patterns and surface finishes are applied for realistic visualization and technical clarity. This 3D mosque drawing supports architectural planning and religious building design.

The AutoCAD DWG file also features sectional massing, boundary walls, seating areas, and service zones for complete site coordination. It is compatible with AutoCAD, Revit, SketchUp, and 3ds Max, allowing easy modification, scaling, and integration into BIM workflows.
