This AutoCAD DWG file provides detailed plumbing and drainage system drawings for residential service areas including kitchen, gourmet area, bathrooms, lavatory, and laundry. Each fixture connection is illustrated with precise cold water, hot water, sewage line, and ventilation pipe routing, ensuring accurate installation in construction and renovation projects.

The kitchen and gourmet area details include gas line diagram, sink water supply, drainage outlet, and connection to external treatment or sewer system, supporting correct alignment during masonry and finishing phases.

Bathroom and lavatory drawings show toilet, shower, lavatory basin, ventilation risers, and trap connections, helping avoid installation conflicts and ensuring proper hydraulic performance. Laundry system detailing presents washing machine drain, water supply, and floor drain layout.

Key Highlights:

Water supply and sewage line diameters clearly indicated
Cross section views for vertical pipe routing and wall penetration
Fixture-to-pipe connection diagrams for site execution
Optimized layout to prevent backflow and clogging issues

This DWG file is valuable for architects, civil engineers, plumbers, MEP designers, contractors, and students involved in hydraulic and sanitary system design.
