Two Storey House Cross Section 3 point 00m Floor Height Detail

This house cross-section drawing presents a detailed two-storey house cross-section with clear structural and level information. The section indicates floor-to-floor height of 3 point 00m, internal clear heights of 2 point 80m, and stair landing levels marked with plus 0 point 00 and 2 point 75 references. The drawing shows RCC slab thickness, reinforced concrete beams, load-bearing concrete wall sections, and a stepped foundation detail with stone masonry base. Window and door openings are vertically aligned with sill and lintel levels dimensioned for construction accuracy.
