Single Floor House Elevation Section DWG with Height Dimensions Detail

Explore a detailed single-floor house elevation section DWG designed for accurate residential architectural planning and visualization. This AutoCAD drawing includes complete elevation and sectional views of a single-storey house, providing clear insight into external appearance and internal structural composition. The elevation showcases facade elements such as doors, windows, roof design, and wall finishes with proper proportioning. The sectional view highlights internal components, including foundation, plinth level, floor slab, wall thickness, and roof structure, with typical floor heights ranging from 3000 mm to 3300 mm and slab thickness around 120 mm to 150 mm.
