Roof Truss Structure Detailed with Zincalum Cover 0.35mm Section

Roof truss structure detail with zincalum cover 0.35mm presents a complete construction and structural section including trusses 32 x 90 pine BTI members and 45 x 45 mm native battens. The drawing specifies zincalum sheet 0.35 mm type toled under cover with filter N10 layer and proper slope indication of minimum 30 percent. Ceiling build-up includes gypsum board 10 mm over 0.05 mm polyethylene, glass wool insulation 40 mm and 120 mm thickness, and a smart panel 11.1 mm facade system. Eave projection is dimensioned at 300 mm with detailed fascia and gutter alignment.
