RCC Structure Detail 6.81m Span 4.5m Height Foundation Plans

Structure Detail CAD Drawing Beam Support Section Layout is a technical AutoCAD DWG file presenting a detailed structural section with reinforced concrete beam configuration and inclined support members. The drawing illustrates a main horizontal beam with sloped structural arms anchored to concrete foundation blocks on both ends. Clear dimensional references indicate span lengths, support widths, depth variations, and level markings to ensure accurate construction alignment and load transfer understanding.
